Pavers Shot Blasting Machine

Free Quote

Paver shot blasting machine is mainly used for surface roughening treatment of marbles, granites, concrete products, and natural stone. It provides twin advantage foremost subject field end provides outstanding appearance as a result of the rough surface and therefore the exposed aggregates. Second "roughened" surface has excellent non-slip properties.

  • paver shot blasting machine 3
  • paver shot blasting machine 1
  • paver shot blasting machine 2
  • paver shot blasting machine 4
  • paver shot blasting machine 3
  • paver shot blasting machine 1
  • paver shot blasting machine 2
  • paver shot blasting machine 4
  • paver shot blasting machine 3
  • paver shot blasting machine 1
  • paver shot blasting machine 2
  • paver shot blasting machine 4

NEWS

Contact

Pavers Shot Blasting Machine Basic Specification

QGS Series Roller Conveyor Type for Pavers Length ≥60cm

Machine Model

QGS600

QGS800

QGS1000

QGS1200

QGS1500

Max. working width of machine(mm)

600

800

1000

1200

1500

Max. working height of machine(mm)

400

400

400

400

400

Working speed(frequency adjustable) m/min

0.5~6

0.5~6

0.5~6

0.5~6

0.5~6

number of wheels×power(kw)

2×7.5/11/15

2×7.5/11/15

2×7.5/11/15

2×7.5/11/15

2×7.5/11/15

Vertical wheel optional

1×7.5/11/15

1×7.5/11/15

1×7.5/11/15

1×7.5/11/15

1×7.5/11/15

Foundation pit required

No

No

No

No

No


pavers shot blasting machine 1

QGP Series Rubber belt Type for Pavers Length ≤60cm


Machine Model

QGP600

QGP800

QGP1000

QGP1200

QGP1500

Max. working width of machine(mm)

600

800

1000

1200

1500

Max. working height of machine(mm)

400

400

400

400

400

Working speed(frequency adjustable) m/min

0.5~6

0.5~6

0.5~6

0.5~6

0.5~6

number of wheels×power(kw)

2×7.5/11/15

2×7.5/11/15

2×7.5/11/15

2×7.5/11/15

2×7.5/11/15

Vertical wheel optional

1×7.5/11/15

1×7.5/11/15

1×7.5/11/15

1×7.5/11/15

1×7.5/11/15

Foundation pit required

No

No

No

No

No



pavers shot blasting machine 2

The working principle of the paver shot blasting machine:

Paver Shot Blasting Machine is predominantly used to blast marbles, granites, concrete blocks to create an improved aesthetic appearance, taking out cement and making styling attributes such as granite chips visible. The working principle: different sized abrasive, thrown by the rapidly rotating blast wheel, is accelerated towards the surface being prepared. The huge impact force of the abrasive quickly etches a unique three-dimensional character of the surface. The products processed in this way have a high-quality surface appearance without overlapped and dead zone, it also has high production efficiency and low cost. Comparison with the old power blader and singeing process method, it has higher efficiency and lower cost, and if connected to our dust collector, the dust and contaminants will be recycled automatically at a very low dust emission level, which complies with EU environmental standards.

The concrete block/stone blast machine can be integrated into a production line due to its modern control system with the relevant interfaces, different belt lengths and well-coordinated transfer stations (e.g. sheets or rollers).

pavers shot blasting machine 3

Advantage of paver shot blasting machine:

  1. Speed adjustment of conveyor and blast wheels is controlled through an Inverter.

  2. The number and the position of the blast wheels can change depending on the geometry, customer requirement and on the workpieces, such as only the blasting of the upper side, or need to blast lateral side.

  3. With proper regulated control and type of shot used in the shot blast machine, it is possible to produce different surface finishes to produce an "antique" effect on marble stones and ‘bush-hammering's effect on cement products.

  4. All paver shot blasting machine with Blow-off station. After blasting, a blow-off station with a high-pressure blower removes the shot from the surface of the concrete blocks/stone. The nozzles are adjustable in height and therefore adaptable for the treatment of different concrete block/stone sizes.



pavers shot blasting machine 4

pavers shot blasting machine 5
