Features and advantages of tumble belt shot blasting machine structure

Tumble belt shot blasting is a new product designed by comprehensive foreign technology research and design. It uses a new high-efficiency single-disc blast turbine and a hypothetical roller surrounded by rubber belts to make the cleaned workpieces roll evenly and reduce collisions. The cleaning effect is good. The work can be automatically completed. Unloading, tumble belt shot blasting is widely used in small and medium-sized castings, forgings, stamping parts, non-ferrous metal castings, gears and springs for sand cleaning, descaling and surface strengthening. The tumble belt shot blasting is equipped with a dust collector to achieve environmental protection, emission Standards. We have tumble blaster for sale. With low noise, less space, stable performance, safety and reliability, it is an excellent and ideal cleaning equipment in China.


Tumble belt shot blasting machine has many functions and several combinations:


It has good separation effect and high productivity, and has a positive effect on improving the blade. Tumble belt shot blasting machine adopts cantilever centrifugal sandblasting machine with large projection angle, high efficiency and no dead angle. Long life and simple structure; wear-resistant rubber tracks reduce collisions and damage to workpieces, and reduce machine noise; orbital shot blasting machine adopts DMC pulse recoil bag filter, and the dust emission concentration is lower than national regulations. This standard greatly improves the operator's working environment.

Features and advantages of tumble belt shot blasting machine structure1.jpg

The working principle of the tumble belt shot blasting machine is relatively simple, but there are also many points worth noting. After adding a specified number of workpieces in the blasting chamber, close the door, start the machine, drive the workpiece through the roller belt, start to rotate, and then throw the blast turbine at high speed. The projectile forms a fan-shaped beam and strikes evenly on the surface of the workpiece for cleaning. The thrown projectiles and sand particles flow from the small holes on the track to the screw conveyor at the bottom, and are sent to the elevator through the screw conveyor, and the hopper is separated into the separator for separation.

The dust-containing gas is sucked into the dust collector through the fan, filtered into clean air and discharged into the atmosphere. The dust of the tumble belt shot blasting machine is blown back to the dust box at the bottom of the dust collector through the air, and the user can clean it regularly. The waste sand is discharged from the waste water pipe and can be reused by the user. The sprayed mixture is recycled to the chamber body through the recirculation pipe, and is reused after being separated by the separator. The layout of the shot blasting machine is simulated through computer three-dimensional dynamics, and the angle and position of all layouts are determined through computer design.

Features and advantages of tumble belt shot blasting machine structure2.jpg
